General data

• DisplayFront panel multi-color LED
• Cabinet DesignDual passive radiator
• Cabinet MaterialPC-ABS
• Mounting optionsFlat on desk or loudspeaker stand (angled 15 degrees upwards on desk using supplied foot), threaded insert (3/8″) on the bottom of the cabinet for microphone stand
• Power consumption (max, idle, sleep)60 W, 5 W, 0.3 W
• AC Input Voltage100 – 240 V, 50/60 Hz
• Power Rating60 W max.
• Operating Conditions-10° C to +45° C (+14° F to +113° F); <70% RH, non-condensing
• Weight3.58 kg total (7 lbs 14 oz total)
• Dimensions (Height x Width x Depth)200 mm (Height with stand: 240 mm) x 115 mm x 150 (7 7/8″” (Height with stand: 9 1/2″”) x 4 1/2″” x 5 7/8″”, 9 1/2″”)”
• Length of connection cable2 metres (78.74 inches)
• Warranty5 years (2 years warranty plus 3 years optional with product registration)
• Delivery ContentsD3V primary loudspeaker, D3V secondary loudspeaker, USB-C cable with USB-A adpater, Connection cable, Power cable, Power block, Quick Start Guide

Audio Connectors

• AnalogTRS
• Input Impedance47 kOhm
• Max. Input Level+9 dBu
• DigitalUSB Type C
• Digital Audio SignalClass-compliant USB 1.1
• Headphones output connector3.5 mm TRS mini-jack
• Headphones output impedance32 Ohm

Amplification

• • Woofer:
  • Amplifier TypePWM
  • Peak (10% THD, limiter deactivated)2 x 80 W
  • RMS (1% THD, limiter deactivated)2 x 70 W

• Tweeter:
• Amplifier TypePWM
• Peak (10% THD, limiter deactivated)2 x 80 W
• RMS (1% THD, limiter deactivated)2 x 70 W

Control Options

• • Input sensitivity0 dBu = 88 dB SPL at 1 m @ 0 dB level setting
  • LevelFront panel knob controls loudspeaker and headphone outputs over the range -∞ dB to +6 dB
  • Front panel knob press functionsMute, standby, input select, channel swap, firmware update mode
  • Input selectionAnalog, USB-C
  • Channel orderNormal, L/R swapped

• Backplate Room AdaptionYes
• Position (Bass)0, -3, -6 dB
• Desk (Low-mid and Mid)0, -3, -6 dB and 0, -2, -4 dB
• Room Acoustics (Treble)0, -1.5, -3 dB

Acoustics

• Frequency Response @ -3 dB48 – 22.6 kHz
• Frequency Response @ -6 dB45 – 23.2 kHz
• Crossover Frequencies4.0 kHz
• Max SPL in full space at 1 m with sine bursts (average 100 Hz to 6 kHz) @ 3% THD (RMS)94 dB SPL
• Max SPL in full space at 1 m with sine bursts (average 100 Hz to 6 kHz) @ 3% THD (Peak)97 dB SPL
• Max SPL in full space at 1 m with sine bursts (average 50 Hz to 100 Hz) @ 3% THD (RMS)80 dB SPL
• Max SPL in full space at 1 m with sine bursts (average 50 Hz to 100 Hz) @ 3% THD (Peak)84 dB SPL
• Max peak SPL in full space at 1 m with IEC-weighted noise (full range / 80 Hz bass managed)98 dB SPL
• Dolby DARDT max SPL in full space103 dB SPL
• Dolby DARDT max SPL in full space (bass managed)106 dB SPL

Drivers

• • Woofer:
  • Basket Diameter3.5″
  • Voice Coil Diameter1″
  • Cone MaterialSingle-piece aluminium
  • Passive Radiator Basket Diameter2 x 3.5″

• Tweeter:
• TypeD-ART
• Diaphragm Area2.8 inch² (1800 mm²)
• Equiv. Diaphragm Diameter1.9″ (48 mm)
• Velocity Transform Ratio5 to 1
• Diaphragm Weight0.085 g
• Tweeter Dispersion120° horizontal, 120° vertical

Signal Processing

• AD converter24-bit (via TRS inputs)
• USB bit depth16-bit (via USB-C input)
• Internal sample rate48 kHz
• ProtectionIndependent peak and thermo limiters for each driver, and amplifier thermo limiters
